LED signal luminaire LR40-RGBW

€15.00*

Prices incl. VAT plus shipping costs

Connection Type
Cover
Lengths
Lumen (White)
Power (White)
Item Number: 1-000000-06973
catalog number: 15070984

3D models download   |  data sheet download



  • Technical Details
  • Product information
  • application areas
Item Number:1-000000-06973
catalog number:15070984
Light Colour:5.000 K
Main supply: 24 VDC
Dimmable: yes, external PWM
Protection class: 3
Power:17,2 W
Colour Rendering:Ra / CRI ≥ 80
Operating Temp: -20°C / +45°C
Lifetime:60.000 h
Optics:100°
Connection Type : M12 5pol. a-codiert
Housing: Aluminium
Fastening: Drehbar
Product information "LED signal luminaire LR40-RGBW"
The features of our LR40 Standard supplemented by the signalling function of an RGB luminaire. Our LR40-RGBW surface-mounted luminaire for illuminating and signalling is a real all-rounder thanks to its many features. Power supply of 24V, robust and optimised for use in particularly harsh environments, e.g. CNC milling machines with chip impact.
Connection Type: loop through, not loop through
Cover: ESG diffuse, PMMA diffuse
Lengths: 190 mm, 365 mm, 610 mm, 1040 mm
Light Color: RGBW
Lumen (White): 263 lm, 266 lm, 526 lm, 533 lm, 1051 lm, 1066 lm, 1840 lm, 1865 lm
Power (White): 4,3 W, 8,6 W, 17,2 W, 30,2 W
IP-Schutzart: IP67
Zulassung: CE, D, SK3, UKCA, UL
  • Status display, status indicator, fill level indicator
  • Machine tools, etc.
  • Use of water, coolants and lubricants
  • Harsh environments
